| MODEL | C-Sport 2 Acera 24sp |
| CODE | YRBD9 |
| COLOR | CC: CK16/Dark Turquoise Full Glossy C9: Rocks Sand/Black Matt/Glossy |
| FRAME | C-SPORT StepThru alu disc frame, 700C Old 135mm, integrated cable routing, Smooth Welding, 1.1/8" headset (semi-integrated down HT tube and integrated in top top HT tube). Seat tube
31.6mm, size: 43,47, 51, 55, 59 |
| SEATPOST CLAMP | MX-112C alloy, diam. 34.9mm |
| HEADSET | Fsa No.8B/ZS4D 1.1/8" Semi-Integrated lower part + Integrated upper part, w/cap 15mm |
| FORK | Alu Disc, 1.1/8", Post mount, max tire size 700x40c |
| SHIFTER | Shimano ST-EF505 3x8sp |
| REAR DERAILLEUR | Shimano Acera RD-M360-L SGS 8sp, direct attachment |
| FRONT DERAILLEUR | Shimano Tourney FD-TY700-TS3,Top-Swing, Dual-Pull, Band Type (34.9mm), 63-66°, For 42T, CL: 47.5/50mm |
| CRANKSET | Shimano FC-TY301, 42x34x24T, crank lenght: 170mm-43/47cm, 175mm-51/55/59cm |
| BOTTOM BRACKET | Shimano BB-UN101, Spindle: Square Type, Shell: BSA 68mm, Spindle:122.5mm |
| CHAIN | Kmc Z-72 8sp |
| CASSETTE / FREEWHEEL | Shimano CS-HG200-8, 8sp, 12-14-16-18-21-24-28-32T |
| BRAKE | INCLUDED IN L/SHIFTER |
| BRAKE LEVER | Included w/brakeset |
| DISC ROTOR | Shimano SM-RT10 diam.160mm, Center Lock, Resin Pas only |
| FRONT HUB | Formula CL-1420 Center lock, 32hole, 14G, OLD 100mm, with QR |
| REAR HUB | Formula CL-1422 Center lock, 32hole, 14G, OLD 135mm, with QR |
| RIM/WHEELSET | Alex Rim ATD500 disc version, alloy, 700c 622x19, 32h, tubeless ready |
| TIRE | Kenda Kwick Tendril 700x38c, 60Tpi, w/Kshield 3mm antipunctures insert |
| STEM | 3D forged 6061 Alloy, 12° 31,8mm 1.1/8", ext: 70mm-43cm, 100mm-47/51cm, 120mm-55/59cm |
| HANDLEBAR | Alloy 6061 DB, width: 620mm, flat bar, 9° bend, 31.8mm |
| GRIP / TAPE | Bianchi Ergonomic Double density, 131.6mm |
| SEATPOST | AL6061 shaft, alloy head, 15mm offset, diam.31.6mm |
| SADDLE | Selle Royal black-ck cover |
